Multi Parameter Patient Monitor (12 inch) - Pro6
Standard Configurations:
12.1-inch LED, 3/5 Lead ECG, NIBP, SpO2, Pulse Rate, Temperature, Respiration
General Introduction
Pro6 is a 6 parameters patient monitor, HR, NIBP, SPO2, PR, RESP, TEMP.
Press the “MENU” icon can enter the main menu;
Press the “Patient Information” icon can register patient’s information;
Related Products
Support DAT, SCP, PDF, XML, DICOM and worklist, connecting with HIS seamlessly (Optional);
Accuracy:±3 mmHg Measurement Range:0-299 mmHg
10.4-inch color Folded high-brightness TFT LED,Support storage of 25000 groups of the medical records and 8640 hours trend review
- Accessories
- Manufacturing
Multiple Parameters Available
Standard Configurations: 12.1-inch LED, 3/5 Lead ECG, NIBP, SpO2, Pulse Rate, Temperature, Respiration
12.1 Inch Multi Parameter Patient Monitor
PRO6
Features:
Core
- Newly advanced A9 mainboard with Linux OS
- Support storage of 2160 hours trend table and graph review, 2 hours waveform review, 2000 groups NIBP review and 2000 alarm events review
Body
- 1 inches high-brightness TFT LED
- Support display 9~13 waveforms
- Support 7 channel ECG waveform display simultaneously
- Optional HDMI output
Printer
- Built-in high-speed 50mm thermal printer
Central System
- Wired or wireless connection
Alarm
- Three-level acousto-optic alarm
- Sensor-off alarm
- Paper out alarm
- Support alarm review
- Support alarm pause
Linux OS
- Support operation with USB mouse and computer keyboard (option)
- Multi-display mode
- NIBP self-test mode
- Support medical history search by patient ID, name and mobile number
- 13 types of Arrhythmia analysis and real-time S-T segment analysis and pacemaker detection
- Drug calculation and titration table
- Multi-language display
- Online software upgrading by net/USB
Model Configuration
| Optional Configuration: | 2-Temperature, 1/2 IBP, Digital SpO2, Perfusion Index (PI), Laser Printer Interface |
| Optional Accessories: | Touch Screen, Printer, Central Monitoring Station, Neo/Ped Accessories, Wall-mounting, Trolley |
