Digital Electrocardiograph ECG Machine, e1200/e1200plus
Features:
- Design patent, software copyright patent;
- Full keyboard, touch screen operation;
- Advanced Might-gold algorithm for automatic accurate measurements and interpretation;
- Sampling rate up to 16000Hz, pacemaker detection;
- Supporting 9/12-lead ECG Configurable;
- Supporting accurate digital filter to decrease the polarization voltage and other interference;
- Save up to 1000 ECG records internally (expandable with USB flash-disk);
- Advanced ECG analysis: VCG/TVCG/VLP/HRV/Pharmacological Study (Optional);
- Support DAT, SCP, PDF, XML, DICOM and worklist, connecting with HIS seamlessly (Optional);
- Two Lithium-ion batteries, suitable for different applications (Optional);
- Support external USB Printer, Keyboard, Mouse, Bar-code scanner, etc;
- Data transfer to PC directly by Ethernet, USB or Wi-Fi (Optional);
- Data upload automatically through FTP or Might-net ECG management system.
Related Products
Accuracy:±3 mmHg Measurement Range:0-299 mmHg
10.4-inch color Folded high-brightness TFT LED,Support storage of 25000 groups of the medical records and 8640 hours trend review
12.1-inch color Folded high-brightness TFT LED,Support storage of 25000 groups of the medical records and 8640 hours trend review
Pro6 is a 6 parameters patient monitor, HR, NIBP, SPO2, PR, RESP, TEMP.
- Manufacturing
Digital Electrocardiograph
12 Channel ECG Machine E1200/E1200Plus
Features
- Design patent, software copyright patent;
- Full keyboard, touch screen operation (1024×768 resolution);
- Advanced might-gold algorithm for automatic accurate measurements and interpretation;
- Sampling rate up to 16000Hz, pacemaker detection;
- Supporting accurate digital filter to decrease the polarization voltage and other interference;
- Save up to 1000 ECG records internally (expandable with USB flash-disk);
- Advanced ECG analysis: VCG/TVCG/VLP/HRV/Pharmacological Study (optional);
- Support DAT, SCP, PDF, XML, DICOM and worklist, connecting with HIS seamlessly (optional);
- Two Lithium-ion batteries, suitable for different applications (optional);
- Support external USB printer, Keyboard, Mouse, Bar-code scanner etc;
- Data transfer to PC directly by Ethernet, USB or Wi-Fi (optional);
- Data upload automatically through FTP or Might-net ECG management system;
| Display | Power | ||
| Resolution | 1024×768 | AC Frequency | 50/60 Hz |
| Type | 7″ TFT screen (e1200) 9.7″ TFT screen (e1200plus) |
Power Supply | AC input with external power adapter, 100V-240V |
| Operation | Touchscreen | Battery | Rechargeable Lithium-ion battery, 4400mAh |
| Capacity | More than 3 hours continuous operation or 400 ECGs printing | ||
| Requisition | Printer | ||
| Leads | 9/12 leads | Gain | 2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV, 10/5mm/mV, AGC±5% |
| Sampling Frequency | 16000Hz | Speed | 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s (±3%) |
| A/D Resolution | 24bits | Recorder | Thermal dot-matrix recorder; |
| HR Range | 30-300BPM | Printing Density | 8 dots per mm / 200 dots per inch (amplitude axes) 40 dots per min / 1000 dots per inch (time axes, @25 mm/s) |
| Accuracy | 1BPM | ||
| Time Constant | ≥3.2s | Physical | |
| Input Circuit Current | ≤0.01μA | Dimension | 369x260x83mm |
| Input Voltage Range | ≤ ±5mVp-p | Weight | 3.8kgs |
| Calibration Voltage | 1mV±2% | ||
| DC Offset Voltage | ±600mV | Safety | |
| Input Impedance | ≥50MΩ (10HZ) | Anti-electric-shoch degree | CF type with defibrillation-proof, class I equipment |
| CMRR | ≥120dB | Defibrillation-proof recovery time | ≤5s |
| Frequency Response | 0.01-300Hz +0.4dB -3.0dB | Patient Leakage Current | NC: ≤10uA(AC) / ≤10uA(DC) SFC: ≤50uA(AC) / ≤50uA(DC) |
| Noise | ≤12.5μV(P-P) | Patient Auxiliary Current | NC: ≤10uA(AC) / ≤10uA(DC) |
| AC Filter | 50Hz/60Hz/Off | ||
| DFT Filter | 0.01HZ/0.05HZ/0.32HZ
/0.67HZ |
||
| EMG Filter/Low-pass | 25Hz/35Hz/45Hz/75Hz/100Hz
/150Hz/270Hz/300Hz |
||
| Pacemaker Detection | Amplitude: ±750uV~±700mV; Width: 50us~2.0ms Sampling Frequency: 16000Hz |
||
